| Specification |
| Fan Dimension : 120x120x25 (mm) |
Max. Air Static Pressure: 0.47mmH2O
|
| Rated Voltage：12 (V) |
Bearing Type: Extended Sleeve Bearing
|
| Started Voltage : 9 (V)
|
Acoustic Noise: 14 dB(A) |
| Rated Current : 0.08 (A) |
Life Expectation: 50000 hrs
|
| Power Input : 0.96 (W) |
Connector : 3 pin + 4 pin
|
| Fan Speed : 800 + - 10% rpm |
Weight : 148 (g) |
| Max. Air Flow Rate: 33.1 CFM |
Screw holes pitch : 105 x 105 (mm)
|
